Outlet 🔥 BetaFPV Toothpick F405 V4 2-4S AIO Whoop/Toothpick Flight Controller For DJI W/ 20A 32Bit 4in1 ESC 🔥

Motor header plugs are unattached from the manufacturer, You will need to solder the motor plugs if needed.

BetaFPV has listened to the community and brought forth a plug-and-play ready AIO FC. The layout has been specifically designed to keep your build as clean as possible and keep like pads near each other. The F405 FC paired with the 32Bit 20A ESC will provide all the power and computing necessary for those precise and controlled flights.

Check out all our Whoop/Toothpick FCs, and all our BetaFPV products!

Features

• Plug and play ports for DJI and Receivers
• F405 FC
• 32Bit 20A ESC

Specifications

F405 FC

• CPU: STM32F405RGT6
• Gyro: BMI270
• Size: 26mm x 26mm, whoop mounting pattern
• Firmware version: Batefight-BETAFPV405-4.2.X
• OSD: Built-in BetaFlight OSD (STM32 controls OSD chip over SPI in DMA mode)
• Receiver: Support Frsky XM/XM+ Receiver/ Futaba Receiver/ Flysky Receiver/ TBS Crossfire Receiver/DSMX Receiver
• Connecter: XT30
• Weight: 5.76g

20A 32Bit 4in1 ESC

• Support PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300，Dshot600
• Input voltage: 2S-4S Lipo
• Continuous current: 20A
• Peak current: 22A
• Firmware: BLHELI-32

Includes

• 1x BetaFPV Toothpick F405 V4 2-4S AIO Whoop/Toothpick Flight Controller for DJI w/ 20A 32 Bit 4in1 ESC
