New ⌛ Matek Micro BEC 6-60V To 5V/9V/12V New 🛒

Get the voltage you need with this Matek BEC, convert 6-60V to either 5V, 9V, or 12V.

This BEC defaults to 5V, select either 9V or 12V by soldering the respective jumper.

Check out all our BECs and PDBs, as well as the entire Matek selection!

Specifications

• Wide 6V to 60V Operating Input Range
• Start-up Voltage >=6.7V
• VOut 5V, 9V or 12V Adj. Default is 5V.
• Maximum Duty Cycle: 100%,   when input voltage< setting value,  Regulator output voltage = Input voltage
• Continuous load current: Depends on input voltage and heat dissipation.
• Standby current: <5mA
• OCP Protection and Hiccup
• Thermal Shutdown
• Output Short-circuit tolerant (3 seconds/minute)
• No protection for reversed input polarity
• Pins distance: 2.54mm
• Size & Weight: 18x15x4.5mm, 2g

Includes

• 1x Matek Micro BEC 6-60V to 5V/9V/12V
