Buy 😉 SkyStarsRC F7 WIFI 3-6S 30×30 Flight Controller New 🔔

The all-new SkyStarsRC F405 HD2 flight controller is compatible with Betaflight and INAV Firmware.  This flight Controller also comes equipped with a powerful BEC to regulate all that power to your  DJI connector on the board as well as your nice large solder pads. This FC is safe! Coming in with a TVS Diode for Reverse Polarity and Voltage Spike Suppression it’s ready for whatever you throw at it!

Check out all our 30×30 FCs and our SkystarsRC collection!

Specifications

•  MCU:  STM32F722RGT6 216MHz 32BIT
• IMU: BMI270 (SPI)
• Barometer: Yes
• OSD: Betaflight OSD &  DJI HD OSD (UART6)
• 6 hardware UARTS (UART1,2,3,4,5,6,)
• Receiver: TBS/PPM/SBUS/IBUS/DSM
• ESC Telemetry: RX3
• Blackbox: 16MB
• ESC Soft: Dshot300/600/1200
• LED indicator: Blue for FC Status,Red 5V
• WIFI: SpeedyBee APP target name SKYSTARS F7
• Input voltage: 3-6S LiPo(11.1V~25V)
• LED Controller: 4 corner LED interface to support BF led
• Pit mode:YES
• RSSI Pad: YES
• Buzzer Pad: YES
• CURR Pad: YES
• Smartaudio: YES
 •BEC 5V 2.5A & 10V 2.5A(Max 3A)
• Firmware: SKYSTARS F7HDPRO
• Dimensions: 38.5x40x6.2mm
• Mounting Holes: Standard 30.5mm square to center of holes
• Weight: 6.6g

INCLUDES

• 1 x SkyStarRC F7 WIFI 3-6S 30×30 Flight Controller

Wiring
