Best Pirce 👏 Skyzone SKY04X V2 OLED Diversity 5.8GHz FPV Goggles – Choose Your Color New ❤️

V2 now comes equipped with a 60FPS DVR unit!

The SKY04X is First skyzone goggle with focus adjustment,the 1280*960 high resolution screen have vivid color and high contrast ration, pilot can see more details in the racing.

With Steadyview receiver, the receiver merge two signal to one, avoid image tearing and rolling, make image more stable and clear in challenging condition.

The new designed optics have focus adjustment feature and 46 degree Field of view, gives pilots more immersive FPV experience.

The new OS with 10 languages to set select, pilot have no trouble with the menu system, with shuttle wheel and new user interface, pilot can set all the setting just by rolling the wheel without take off the goggles.

Not compatible with Foxeer Wildfire, TBS Fusion, True D V3, and LaForge main Mod V2/3 modules.

Check out the rest of our FPV goggles and accessories and all our Skyzone gear!

Features

• SteadyView receiver merges two signal to one, make image more stable and clear in challenging condition.
• Module bay, goggles have more capability to upgrade.
• Focus Adjustmentm, The new Optics have large Field of View (46 degree). and the Optics have Focus adjustment feature (-6~+6), no need diopter any more.
• OELD Screen, The 1280*960 screen have high resolution and vivid color, high contrast ration, pilots can see more details.
• Advanced Screen Settings, The aspect ration can is switchable, and 4 Preset screen setting and 3 customized setting for indoor, outdoor flight or different weather.
• Shuttle Wheel Control, No more confusing multi function button or 5 way Joy stick, with smooth and nature shuttle control, easy to navigate.
• New User Interface with 10 languages, New UI with shuttle wheel, easy to navigate, 10 languages to choose for local user.
• Built-in DVR

Specifications

• Screen: OLED
• Resolution: 1280X960
• FOV (Diagonal): 46°
• Aspect Ratio: 4:3/16:9
• Focus: -6~+6 adjustable
• Interpupillary distance(IPD): 58-71mm
• Receiver: 5.8Ghz 48CH Steadyview Receiver
• Language: 10 Language
• Power Supply: DC6.5-25.2V/USB5V
• Power Consumption: 720mA at 12V
• DVR: H264,60fps,MOV6Mbps,SD Card support up to128Gb
• Head Tracker: 3-axis Accelerometer, 3-axisgyroscope
• Dimensions: 185*75*67mm
• Weight: 267g

Includes

• 1x Skyzone SKY04X OLED Diversity 5.8GHz FPV Goggles – Choose Your Color

Band/Channel Table

Band/CH	CH1	CH2	CH3	CH4	CH5	CH6	CH7	CH8
A	5865M	5845M	5825M	5805M	5785M	5765M	5745M	5725M
B	5733M	5752M	5771M	5790M	5809M	5828M	5847M	5866M
E	5705M	5685M	5665M	5645M	5885M	5905M	5925M	5945M
F	5740M	5760M	5780M	5800M	5820M	5840M	5860M	5880M
R	5658M	5695M	5732M	5769M	5806M	5843M	5880M	5917M
L	5362M	5399M	5436M	5473M	5510M	5547M	5584M	5621M
Sensitivity	-98dBm±1dBm
Antenna Port	2 X SMA-K,50ohm
